Cup Carrier / Egg Tray Pulp Molding Equipment 3000Pcs To 6000Pcs Per Hour

Cup Carrier / Egg Tray Pulp Molding Equipment 3000Pcs To 6000Pcs Per Hour

Cup Carrier / Egg Tray Pulp Molding Equipment 3000Pcs To 6000Pcs Per Hour
Cup Carrier / Egg Tray Pulp Molding Equipment 3000Pcs To 6000Pcs Per Hour
Cup Carrier / Egg Tray Pulp Molding Equipment 3000Pcs To 6000Pcs Per Hour
Product Details:
Place of Origin: Mainland, China
Brand Name: Nanya
Certification: CE, TUV,SGS, ISO9001
Model Number: ER3000-B~ER6000-B
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Export Standard Packing
Delivery Time: Normally 45-75 days
Payment Terms: L/C, T/T,Cash, Western Union
Supply Ability: 1000 sets/ years
Contact Now
Detailed Product Description
Automation: Fully-automatic Forming Type: Rotary
Capacity: 3000~6000 Pcs/Hour Dryer: 6-Layers
Fuel: Diesel, Heavy Oil, LPG, Natural Gas, Coal, Wood, Steam… Material: Waste Paper
Processing Type: Pulp Molding Machine Voltage: 220V-450V
High Light:

Pulp Molding Production Line

,

Pulp Moulding Machinery

Fully Automatic Pulp Molding Egg Tray Equipment  3000Pcs To 6000Pcs Per Hour


Specifications:


Model type

ER3000-B

ER4000-B

ER5000-B

ER6000-B

Capacity

3000pcs/hour

4000pcs/hour

5000pcs/hour

6000pcs/hour

Workshop Requirement

400m2

500m2

600m2

700m2

Electricity Consumption

~115kw
(170kw installed)

~150kw
(240kw installed)

~190kw
(290kw installed)

~210kw
(350kw installed)

Material Consumption

180~210kg/h

250~280kg/h

320~350kg/h

360~400kg/h

Water Consumption

600~800kg/h

800~1000kg/h

1000~1200kg/h

1200~1400kg/h

Fuel Consumption

(one item selectable)

Natural gas

55~65m3/h

70~80m3/h

85~95m3/h

100~110m3/h

LPG

19~22m3/h

25~29m3/h

31~35m3/h

36~40m3/h

Diesel

45~55kg/h

62~70kg/h

78~85kg/h

90~98kg/h

Heavy oil

46~56m3/h

63~72kg/h

79~87kg/h

92~100kg/h

Steam

1.0~1.2ton/h

1.3~1.5ton/h

1.6~1.8ton/h

1.8~2.0ton/h

Wood

190~220kg/h

250~290kg/h

310~350kg/h

360~400kg/h

Coal

130~150kg/h

160~190kg/h

200~220kg/h

240~270kg/h

Worker requirement

4~5person

4~5person

4~5person

5~6person

Container requirement for shipment

6 x 40HQ

7 x 40HQ

8 x 40HQ

9 x 40HQ

Forming machine

Rotary type with 8 plates. Each for 3pcs/time

Rotary type with 8 plates. Each for 4pcs/time

Rotary type with 8 plates. Each for 5pcs/time

Rotary type with 8 plates. Each for 6pcs/time

Drying production line

20mx2.2mx4m
6-Layers

22mx2.6mx4m
6-Layers

22mx3.0mx4m
6-Layers

22mx3.4mx4m
6-Layers

Remarks:
1. The Capacity calculated base on 30-packed egg tray(size 300x300mm, weight 65g~70g).
2. Workshop size is for reference only and could be adjusted according to actual size of client’s plant .



Descriptions:

  • Fully Automatic Egg Tray Production Line
  • Mainly used for the products with simple structure but in big quantity, such as egg trays, fruit trays, cup carriers and disposable medical care products.
  • This type of production line is constituted by a hydrapulper system, a rotary type forming machine, a multiple-layer drying line, and corollary equipments.
  • Products are output automatically from waster paper or other type of paper. It’s high-efficiency, energy-saving, durable, wieldy and safe.SIEMENS electrical control parts, FESTO & SMC pneumatic control parts. Applys International famous brand of control parts to obtain excellent performance and universality maintainability.


Products Information and Our Warranty:

  • Status: Brand new
  • Product Type: Egg Tray Machine
  • Processing Type: Pulp Molding Machine
  • Place of origin: Guangdong China
  • Brand: NANYA
  • Model Type: ER3000-B~ER6000-B
  • Voltage: 220V-440V
  • Approval: CE, TUV,SGS, ISO9001
  • Warranty: 12 Months
  • After-Sale Service: Engineers available to service machinery overseas


Competitive Advantages:

  • Fully automatic
  • Energy saving and labor utilization
  • High quality egg tray machine
  • Overseas technical support available
  • Proprietary technology
  • TUV Supplier Assessment Certificate
  • SGS Supplier Assessment Certificate CE Certificate
  • Nanya - Chinese famous trademark
  • 30 years experience in this field, Chinese reliable supplier, supported by the government and university.
  • The standing director of Chinese packaging association



Business Terms:



NO.

ITEM

DESCRIPTION

1

Payment Terms

30% down payment by T/T,

70% before shipment by T/T or L/C at sight

2

Delivery Terms

FOB Guangzhou, China.

(Final transaction could be made in C&F or CIF, the freight and insurance should be decided according to the current rate when signing the contract).

3

Delivery Time

45~75 days

4

Packages

Packages suitable for ocean transport.

The small parts are packaged by wooden boxes.

The big parts are protected by wooden support.

5

Installation

Seller should appoint 1-2 engineers to instruct buyer for installation, test-run and training.

All the charges including air ticket, VISA , accommodation and food of the engineers should be responsible by buyer.

Besides, the buyer should pay the engineers subsidy of USD200/person/day and offer translation service.

6

Warranty

12 months after installation

7

After service

  1. The seller will send spare parts for one year use by free.
  2. The seller will provide operating manual, drawing, process diagram for all of the equipments.
  3. The seller will instruct the operation, maintain method for the buyer’s worker after installation.
  4. The seller will instruct the production technology and prescription for the buyer’s engineer after installation;

8

Quotation Validity

90 days after the offering date




Technological process:

Cup Carrier / Egg Tray Pulp Molding Equipment 3000Pcs To 6000Pcs Per Hour 0





Applications:



Egg tray

20,30,40packed egg tray…  quail egg tray

Egg carton

6, 10,12,15,18,24 packed egg carton…

Agricultural products

Fruit tray, seeding cup

Cup salver

2, 4 cup salver

Disposable Medical Care Products

Bedpan, sick pad, female urinal…

packages

Shoe tree, industrial package…

Cup Carrier / Egg Tray Pulp Molding Equipment 3000Pcs To 6000Pcs Per Hour 1
