High Capacity Pulp Moulded Tableware Making Machine / Clamshell Production Line

High Capacity Pulp Moulded Tableware Making Machine / Clamshell Production Line

  • High Capacity Pulp Moulded Tableware Making Machine / Clamshell Production Line
  • High Capacity Pulp Moulded Tableware Making Machine / Clamshell Production Line
  • High Capacity Pulp Moulded Tableware Making Machine / Clamshell Production Line
High Capacity Pulp Moulded Tableware Making Machine / Clamshell Production Line
Product Details:
Place of Origin: China
Brand Name: NANYA
Certification: CE/TUV/SGS/ISO9001
Model Number: TA-10
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: negotiation
Packaging Details: Export Standard Packing
Delivery Time: 45~75 days
Payment Terms: T/T or western Union or L/C or Cash
Supply Ability: 50 sets per month
Contact Now
Detailed Product Description
Product Name: Tableware Making Machine Capacity: 14000 Pcs/h
Automation: Fully-automatic Forming Type: Vacuum Suction / Thermoform
Raw Material: Bagasse Pulp / Bamboo Pulp / Straw Pulp ... Guarantee: 12 Months
Drying Type: Drying In Mould
High Light:

Paper Plate Making Machine

,

Paper Plate Manufacturing Machine

High Capacity Pulp Moulded Tableware Making Machine / Clamshell Production Line





Introduction of the Virgin Pulp Dishware Production line:



The pulp molded paper tableware is usually made of virgin pulp, like sugarcane bagasse pulp, bamboo pulp, wood pulp, straw pulp and etc.
2.The virgin is smashed and mixed in the hydrapulper and adjusted to a certain consistency in the tanks.
3.The fiber in the pulp will cover the wire mesh of the mold by the vacuum and drop down by the air compressor.
4.The wet products will be formed, dried and hot pressed, edge trimmed in the forming machine. Then the dried products will go disinfection processes.





Specifications:



Model Type

TA-10

   Forming Machine  10 sets
   Mould Platen Size 1300*1100mm

Capacity

14000 pcs/h

Workshop Requirement

1000 m2

Electricity Consumption

850 kw

Electricity Installed

400 kw

Material Consumption

250 ~ 270 kg/h

Water Consumption

1000 ~ 1600 kg/h

   Worker Requirement

8 persons

   Container Requirement for Shipment

8 x 40’ HQ

   Forming Type

Vacuum suction, thermoforming

   Drying Method

Drying in mould



Notes:

  1. The Capacity calculated base on 8” round dish(weight ~16g). The capacity may be different for other products.
  2. Workshop size is for reference only and could be adjusted according to actual size of client’s plant.





Descriptions:



  • Fully Automatic Tableware Making Production Line
  • Mainly used for high quality products , such as tableware, dishware and some high-grade pulp molding products.
  • The products are 100% biodegradable and environmental friendly.
  • Status: Brand new
  • Product Type: Tableware Making Machine
  • Processing Type: Pulp Molding Machine
  • Place of origin: Guangdong China
  • Brand: NANYA
  • Model Type: TA-01B~TA-10B
  • Voltage: 220V-440V
  • Approval: CE, TUV,SGS, ISO9001
  • Warranty: 12 Months
  • After-Sale Service: Engineers available to service machinery overseas





Why Choose Us:



  • Established in 1994, NANYA is the earliest Pulp Molding manufacturer in China;
  • Combined with high and new technology with government institution and South China University of Technology, with over 30 R&D personnel;
  • NANYA offers the widest range of both equipment/machine types and platen/tooling sizes, as well as the comprehensive molds;
  • NANYA factory covers an area of 20,000 square meters, contributing to more than 60% of the domestic demands, already exported to over 50 countries and regions;
  • Excellent engineers, sales and after sales service team brings the best service to ensure long-term satisfaction for our customers.





Applications:



Tableware / Dishware

Paper plate, paper cup, paper bowl, clamshell

High quality packages

Mobile phone package, camera package,

Artware

Mask, Christmas balls, Easter Eggs , boutiques…

Disposable Medical Care Products

Bedpan, sick pad, female urinal…

High Capacity Pulp Moulded Tableware Making Machine / Clamshell Production Line 0





Youtube Video Links:





The below are the YOUTUBE Links showing how these semi automatic tableware production line work:

(1) https://www.youtube.com/watch?v=7YLnwE5lqJw

(2) https://www.youtube.com/watch?v=PrmRiMvirr8



For more videos, you can search "Guangzhou Nanya Pulp Molding Equipment Company" on YOUTUBE and subscribe us.





Business Terms



NO.

ITEM

DESCRIPTION

1

Payment Terms

30% down payment by T/T,

70% before shipment by T/T or L/C at sight

2

Delivery Terms

FOB Guangzhou, China.

(Final transaction could be made in C&F or CIF, the freight and insurance should be decided according to the current rate when signing the contract).

3

Delivery Time

45-75 days

4

Packages

Packages suitable for ocean transport.

The small parts are packaged by wooden boxes.

The big parts are protected by wooden support.

5

Installation

Seller should appoint 2 engineers to instruct buyer for installation, test-run and training.

All the charges including air ticket, VISA , accommodation and food of the engineers should be responsible by buyer.

Besides, the buyer should pay the engineers subsidy of USD50/person/day and offer translation service.

6

Warranty

12 months after installation

7

After service

  1. The seller will send spare parts for one year use by free.
  2. The seller will provide operating manual, drawing, process diagram for all of the equipments.
  3. The seller will instruct the operation, maintain method for the buyer’s worker after installation.
  4. The seller will instruct the production technology and prescription for the buyer’s engineer after installation;

8

Quotation Validity

90 days after the offering date
