Nanya fully automatic paper plate thermalforming machine with robot 220-440V

Nanya fully automatic paper plate thermalforming machine with robot 220-440V

  • Nanya fully automatic paper plate thermalforming machine with robot 220-440V
  • Nanya fully automatic paper plate thermalforming machine with robot 220-440V
  • Nanya fully automatic paper plate thermalforming machine with robot 220-440V
  • Nanya fully automatic paper plate thermalforming machine with robot 220-440V
  • Nanya fully automatic paper plate thermalforming machine with robot 220-440V
  • Nanya fully automatic paper plate thermalforming machine with robot 220-440V
Nanya fully automatic paper plate thermalforming machine with robot 220-440V
Product Details:
Place of Origin: Guangdong,China
Brand Name: Nanya
Certification: CE,TUV,SGS, ISO9001
Model Number: BY043
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Export Standard Packing
Delivery Time: Normally 45-90 days
Payment Terms: L/C, , T/T, Western Union
Supply Ability: 1000sets/year
Contact Now
Detailed Product Description
Raw Material: Sugarcane\bamboo\wood\straw Pulp Forming: Vacuum Suction&thermalforming
Drying: Drying In Mold Transfering: Robort Arm
Products: Paper Plate\bowl\cup\cup Lid\clamshell Box Power: 220-400V
Transportation: Shipped By Sea\air\land After-sale Service: Engineers Available To Service Machinery Overseas
Warranty: 12 Months Advantage: Using International Brand Electrical And Pneumatic Components

Fully Automatic Biodegradable Paper Pulp Molding Tableware Thermoforming Machine Production Process



BY series automatic tableware production line is composed of pulping system, forming system, vacuum system, high pressure water system and air pressure system. Using sugarcane pulp, bamboo pulp, wood pulp, reed pulp, straw pulp and other pulp as raw materials, it can produce disposable pulp molded tableware.

The raw material is prepared into a certain concentration of pulp by the process of shredding, grinding, adding chemical additives, etc., and then the pulp is uniformly attached to the customized metal mold to form a wet product product through the vacuum effect, and then the disposable pulp molded catering products are produced by drying, hot pressing, cutting, stacking and other processes.



Nanya fully automatic paper plate thermalforming machine with robot 220-440V 0





Specifications:



 Machine name      BY series tableware making machine           Model               BY043
Mold plate size                          1100*800mm   Product height              <100
Nominal voltage                               380V    Rated power                 5Kw
Working period                      20-80s (adjustable)   Control mode    PLC+touch screen
   Air pressure                        0.6-0.75PMa  Vacuum pressure     -0.06-0.075PMa






























Descriptions:

  • The processes of forming, drying and shaping finishing are done in one machine automatically and continuously.
  • Hydraulic drive pressing
  • Siemens Servo motor driver for transversal moving
  • With auto mould washing and edge washing.
  • PLC + touch screen control
  • Stainless pulp tank
  • The main electrical elements are Siemens.
  • The main pneumatic element is FESTO or SMC.



Competitive Advantages:

  • Fully automatic
  • Energy saving and labor utilization
  • High quality egg tray machine
  • Overseas technical support available
  • Proprietary technology
  • TUV Supplier Assessment Certificate
  • SGS Supplier Assessment Certificate
  • CE Certificate
  • Nanya - Chinese famous trademark
  • 30 years experience in this field, Chinese reliable supplier, supported by the government and university.
  • The standing director of Chinese packaging association



Applications:


Food container Dishware, tableware, lunch box, bowl…
Artware Mask, Christmas balls, Easter Eggs , boutiques…
Disposable Medical Care Products Bedpan, sick pad, female urinal…
High quality packages Mobile phone package, camera package,





Nanya fully automatic paper plate thermalforming machine with robot 220-440V 1





Business Terms:


NO. ITEM DESCRIPTION
1 Payment Terms 30% down payment by T/T,
70% before shipment by T/T or L/C at sight
2 Delivery Terms FOB Guangzhou, China.
(Final transaction could be made in C&F or CIF, the freight and insurance should be decided according to the current rate when signing the contract).
3 Delivery Time 45-90 days
4 Packages Packages suitable for ocean transport.
The small parts are packaged by wooden boxes.
The big parts are protected by wooden support.
5 Installation Seller should appoint 2 engineers to instruct buyer for installation, test-run and training.
All the charges including air ticket, VISA , accommodation and food of the engineers should be responsible by buyer.
Besides, the buyer should pay the engineers subsidy of USD200/person/day and offer translation service.
6 Warranty 12 months after installation
7 After service
  1. The seller will send spare parts for one year use by free.
  2. The seller will provide operating manual, drawing, process diagram for all of the equipments.
  3. The seller will instruct the operation, maintain method for the buyer’s worker after installation.
  4. The seller will instruct the production technology and prescription for the buyer’s engineer after installation;
8 Quotation Validity

90 days after the offering date







Welcome the customers to visit our factory



Nanya fully automatic paper plate thermalforming machine with robot 220-440V 2





Attend exhibitions all over the world

Nanya fully automatic paper plate thermalforming machine with robot 220-440V 3
