Environmental-friendly Pulp Molding Bucket Making Machine for Industrial Pachaging

Name: Environmental-friendly Pulp Molding Bucket Making Machine for Industrial Pachaging
Brand: Nanya
SKU: PF1640-2
Price: 1.00 USD
Availability: InStock
Rating: 4.5 (106 reviews)

Product Details:

Place of Origin:	China
Brand Name:	Nanya
Certification:	CE/TUV/SGS/ISO9001
Model Number:	PF1640-2

Payment & Shipping Terms:

Minimum Order Quantity:	1set
Price:	negotiation
Packaging Details:	Export Standard Packing
Delivery Time:	45~75 days
Payment Terms:	T/T, L/C, Cash or western Union
Supply Ability:	50 sets per month

Contact Now

Detailed Product Description

Product Name:	Pulp Molding Machine	Automation:	Full-automatic
Forming Type:	Vacuum Suction / Thermoform	Standard:	CE/TUV/SGS/ISO9001
Application:	Craft Packaging / Industrial Packaging	Processing Material:	Waste Paper / Wood Pulp / Bagasse Pulp / Bamboo Pulp / Straw Pulp
Drying Type:	Drying In Mould	After-sales Service Provided:	Engineers Available To Service Overseas
High Light:	Pulp Moulding Machines , Pulp Molding Production Line

Environmental-friendly Pulp Molding Machine for Industrial Pachaging Making Machinery

Specifications:

Machine Name	Fully Automatic Forming Machine
Machine Dimension	613018504520 mm³
Quality of Forming Plate	1 set
Quality of Press Plate	2 sets
Forming Method	Vacuum Forming
Drying Method	Thermoforming Drying
Heating Method	By Conduction Oil
Nominal Power	25kw
Nominal Voltage	380V

Descriptions:

The processes of forming, drying and shape finishing are done in one machine automatically and continuously.
Hydraulic drive pressing
Siemens Servo motor driver for transversal moving
With auto mould washing and edge washing.
PLC + touch screen control
Stainless pulp tank
The main electrical elements are Siemens.
The main pneumatic element is FESTO or SMC.

Competitive Advantages:

Fully automatic
Energy saving and labor utilization
High quality industrial packaging forming machine
Overseas technical support available
Proprietary technology
TUV Supplier Assessment Certificate
SGS Supplier Assessment Certificate
CE Certificate
Nanya - Chinese famous trademark
20 years experience in this field, Chinese reliable supplier, supported by the government and university.
The standing director of Chinese packaging association

Production Information and Our Warranty:

Status: Brand new
Product Type: Thermoforming Machine
Processing Type: Pulp Molding Machine
Place of origin: Guangdong China
Brand: NANYA
Model Type: Fully Automatic Forming Machine
Voltage: 220-440V
Approval: CE, TUV,SGS, ISO9001
Warranty: 12 Months
After-Sale Service: Engineers available to service machinery overseas

Business Terms:

NO.	ITEM	DESCRIPTION
1	Payment Terms	30% down payment by T/T, 70% before shipment by T/T or L/C at sight
2	Delivery Terms	FOB Guangzhou, China. (Final transaction could be made in C&F or CIF, the freight and insurance should be decided according to the current rate when signing the contract).
3	Delivery Time	45-75 days
4	Packages	Packages suitable for ocean transport. The small parts are packaged by wooden boxes. The big parts are protected by wooden support.
5	Installation	Seller should appoint 2 engineer to instruct buyer for installation, test-run and training. All the charges of air ticket, VISA , accommodation and food of the engineer should be responsible by buyer. Besides, the buyer should pay the engineers subsidy of USD50/person/day and offer translation service.
6	Warranty	12 months after installation
7	After service	The seller will send spare parts for one year use by free. The seller will provide operating manual, drawing, process diagram for all of the equipments. The seller will instruct the operation, maintain method for the buyer’s worker after installation. The seller will instruct the production technology and prescription for the buyer’s engineer after installation;
8	Quotation Validity	90 days after the offering date
