Ecological Virgin Tableware Making Machine for Automatic Tableware production Line

    • Ecological Virgin Tableware Making Machine for Automatic Tableware production Line
    • Ecological Virgin Tableware Making Machine for Automatic Tableware production Line
    • Ecological Virgin Tableware Making Machine for Automatic Tableware production Line
  • Ecological Virgin Tableware Making Machine for Automatic Tableware production Line

    Product Details:

    Place of Origin: China(mainland)
    Brand Name: Nanya
    Certification: CE,TUV,SGS, ISO9001
    Model Number: TA01~TA10B

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Negotiation
    Packaging Details: Export Standard Packing
    Delivery Time: 60-120 Days
    Payment Terms: T/T, L/C, Cash or western Union
    Supply Ability: 1000 sets/year
    Contact Now
    Detailed Product Description
    Raw Material: Bagassse Pulp / Bamboo Pulp / Straw Pulp / Wood Pulp Heating Method: Electricity / Conduction Oil / Steam
    Capacity: 1800~18000 Pcs / H Drying Mode: Drying In Mould
    After-Sale Service: Engineers Available To Service Machinery Overseas Applications: Dishware / Tableware
    Automation: Fully-automatic Voltage: 220V - 440V

    Ecological Virgin Paper Pulp Molding Equipment / Automatic Tableware production Line




    Specifications:



    Model Type

    TA-01B

    TA-02B

    TA-05B

    TA-10B

    Capacity

    1800pcs/h

    3500pcs/h

    9000pcs/h

    18000pcs/h

    Workshop Requirement

    200m2

    230m2

    600m2

    1200 m2

    Electricity Consumption

    120kw

    390kw

    550kw

    1100kw

    Electricity Installed

    200kw

    250kw

    880kw

    1700kw

    Material Consumption

    25~30kg/h

    50~60kg/h

    120~150kg/h

    250~300kg/h

    Water  Consumption

    80~100kg/h

    150~200kg/h

    500~600kg/h

    1000~1200kg/h

    Worker Requirement

    3 persons

    4 persons

    6 persons

    10 persons

    Container Requirement for Shipment

    1 x 40’HQ

    2 x 40’HQ

    4 x 40’HQ

    8 x 40’HQ

    Forming Type

    Vacuum suction, thermoforming

    Vacuum suction, thermoforming

    Vacuum suction, thermoforming

    Vacuum suction, thermoforming

    Drying Method

    Drying in mould

    Drying in mould

    Drying in mould

    Drying in mould

    Notes:

    1. The Capacity calculated base on 8” round dish (weight ~16g). The capacity may be different for other products.
    2. Workshop size is for reference only and could be adjusted according to actual size of client’s plant.




    Descriptions:

    • Fully Automatic Tableware Making Production Line
    • Mainly used for the products with simple structure but in high quality, such as tableware, dishware and some high-grade pulp molding products.
    • Status: Brand new
    • Product Type: Tableware Making Machine
    • Processing Type: Pulp Molding Machine
    • Place of origin: Guangdong China
    • Brand: NANYA
    • Model Type: TA-01~TA-10
    • Voltage: 220V-440V
    • Approval: CE, TUV,SGS, ISO9001
    • Warranty: 12 Months
    • After-Sale Service: Engineers available to service machinery overseas


    Competitive Advantages:

    • Fully automatic
    • Energy saving and labor utilization
    • High quality tableware making machine
    • Overseas technical support available
    • Proprietary technology
    • TUV Supplier Assessment Certificate
    • SGS Supplier Assessment Certificate
    • CE Certificate
    • Nanya - Chinese famous trademark
    • 20 years experience in this field, Chinese reliable supplier, supported by the government and university.
    • The standing director of Chinese packaging association


    Applications:


    Food container

    Dishware, tableware, lunch box, bowl, cup, clamshell…

    Artware

    Mask, Christmas balls, Easter Eggs , boutiques…

    Disposable Medical Care Products

    Bedpan, sick pad, female urinal…

    High quality packages

    Mobile phone package, camera package,

    Ecological Virgin Tableware Making Machine for Automatic Tableware production Line




    Business Terms:


    NO.

    ITEM

    DESCRIPTION

    1

    Payment Terms

    30% down payment by T/T,
    70% before shipment by T/T or L/C at sight

    2

    Delivery Terms

    FOB Guangzhou, China.
    (Final transaction could be made in C&F or CIF, the freight and insurance should be decided according to the current rate when signing the contract).

    3

    Delivery Time

    75 days

    4

    Packages

    Packages suitable for ocean transport.
    The small parts are packaged by wooden boxes.
    The big parts are protected by wooden support.

    5

    Installation

    Seller should appoint 2 engineers to instruct buyer for installation, test-run and training.
    All the charges including air ticket, VISA , accommodation and food of the engineers should be responsible by buyer.
    Besides, the buyer should pay the engineers subsidy of USD80/person/day and offer translation service.

    6

    Warranty

    12 months after installation

    7

    After service

    1. The seller will send spare parts for one year use by free.
    2. The seller will provide operating manual, drawing, process diagram for all of the equipments.
    3. The seller will instruct the operation, maintain method for the buyer’s worker after installation.
    4. The seller will instruct the production technology and prescription for the buyer’s engineer after installation;

    8

    Quotation Validity

    90 days after the offering date




    Production Process:

    Ecological Virgin Tableware Making Machine for Automatic Tableware production Line





    Youtube Video Link:



    https://www.youtube.com/watch?v=NgZbUYm_IjE





    Working Theory:

    • The track or worker carries the raw material into the conveyor;
    • The conveyor pours down the raw material into the hydrapulper mixing with certain water;
    • The mixed paper pulp will going into the pulp adjustment pond to be adjusted to a certain consistency;
    • Next the pulp will flow into the second pond called supply pond, in which the pulp keeps a consistency stably;
    • The pulp will be bumped into the forming machine. The fiber in the pulp will cover the wiremesh of the mold with the effect of the vacuum. So the wet products are shaped  on the working platform;
    • Then the wet products will be trandferred to the heating area to get dryed and hot pressing automatically.
    • After that the products need to be edged and disinfected.
